Water
too shallow
for a pontoon lift?


THINK AGAIN!

If you have shallow water and a sandy bottom this lift is ideal.

PONTOON LIFTS : Cantilever

The best Pontoon Lift for really shallow water - works with most Tritoon designs.

keep it  simple

Life can be complicated. So keep your summer simple.

Using our Cantilever Pontoon Lift is the  simplest and least  expensive way  to secure your pontoon boat.

LSP20H + LSP04H (model shown)

See below for complete list of models

with specifications & accessories

Expandable design means you can convert from a 20' to a 24' or 28' with the addition of extension kits.



1

Heavy Duty Winch

1 Heavy Duty Winch Heavy duty winch has greater strength and dependability than lightweight “trailer” type winches that are used by other manufacturers. New design allows winch to be positioned on either side of the lift.

2

Dockside Wheel Design

Innovative design extends out 29" from the lift to allow easy cranking from the dock. The NEW 32" diameter wheel is powder coated for a durable finish.

3

Redesigned for Tritons

Improved H unit design with widened V and lowered cross support to accept tritoons in shallow water.

4

Built-In Leg Bracket

With each 4' extension kit.

5

Non Marking Rollers

White polyester rollers gently guide your boat onto the lift without damage or marks.

SPECIFICATIONS

model number load capacity cradle length outside width without legs lift height weight
LSP20H 3600 lbs 20' 47.45" 60" 350 lbs
LSP20H + LSP04H 3600 lbs 24' 47.75" 60" 370 lbs
LSP20H + LSP04H (2) 3600 lbs 28' 47.75" 60" 390 lbs
